Filter Drier Danfoss DML 164

Danfoss Filter driers have a solid core with binding material held to an absolute minimum. There are two types of ELIMINATOR® cores. Type DML driers have a core composition of 100% Molecular Sieve, while type DCL contain 80% Molecular Sieve with 20% activated alumina.

Danfoss Filter driers are designed for applications requiring the highest moisture capacity. ELIMINATOR® type DCL driers are designed for applications requiring high moisture capacity and acid adsorption capacity. Available with solder (cu-plated steel connectors) and flare connections.

Features :

The Core type DML

100% Molecular Sieve core
High drying capacity minimizing the risk of acid formation (hydrolysis)
Recommended for use with HFC and HCFC refrigerants
Will not deplete oil additives

The Core type DCL

80% Molecular Sieve with 20% activated alumina
Perfect core blend for systems that operate at high condensing temperatures and require high drying capacity
Recommended for use with HFC and HCFC refrigerants

The Shell

PED approved for PS 46 bar
Available with solder (Cu-plated steel connectors) and flare connections
Corrosion resistant powder-painted finish. Special coating for marine applications available upon request
Allows installation with any orientation provided the arrow is in the flow direction
Available in sizes 3 – 75 cubic inches

The Filter

25 μm (0.001 in.) filter provides high retention with minimal pressure drop
Thermally stable up to 120 °C

Model List

Flare Connections

MODEL	SIZE (inch)
DML 032	1/4”
DML 033	3/8”
DML 053	3/8”
DML 083	3/8”
DML 084	1/2”
DML 163	3/8”
DML 164	1/2”
DML 165	5/8”
DML 304	1/2”
DML 305	5/8”

Solder Connections

MODEL	SIZE (inch)
DML 032S	1/4”
DML 053S	3/8”
DML 083S	3/8”
DML 084S	1/2”
DML 163S	3/8”
DML 164S	1/2”
DML 165S	5/8”
DML 304S	1/2”
DML 305S	5/8”
DML 307S	7/8”
